The Cub Cadet Ultima Series ZTX4 54 is a 54-inch zero-turn lawn mower built with a 26 HP Kohler Pro 7000 series engine and dual hydrostatic transmissions for responsive control. Its AeroForce Max reinforced fabricated deck is designed to deliver a high-quality cut with few clumps and an even finish.
| Series | Ultima Series™ ZTX |
|---|---|
| Engine Brand | Kohler® |
| Engine Series | Pro 7000 series |
| Engine Displacement | 747cc |
| Engine Output (HP) | 26HP |
| Cylinders | Twin |
| Starter Type | Electric |
| Fuel Tank Capacity | 5.5 gal. US (20.82 L) |
| Transmission Type | Hydrostatic |
| Forward Speed | 8 MPH /12.9 km/h |
| Reverse Speed | 3.5 MPH / 5.6 km/h |
| Cutting Width | 54 in |
| Deck Type | Reinforced Fabricated |
| Deck Engagement | Electric |
| Cutting Height Range | 1" - 4.75" |
| Cutting Positions | 17 |
| Frame Construction | 1.5" x 3" tubular steel |
| Steering | Lap Bars |
| Front Tires | 13"x 6.5"-6" |
| Rear Tires | 22"x 12"-12" |
| Tire Tread | Turf Master / Multi Trac |
| Headlights | Dual-LED |
| Residential Warranty | 4-year 800 hours |
| Frame Warranty | Lifetime Limited |
| Deck Shell Warranty | Lifetime limited |
| Engine Model Number | KT745 |
|---|---|
| Engine Start | Ignition Key |
| Engine Oil Capacity | 2.0 qt. US (1.89 L) |
| Lubrication | Fully pressurized |
| Charging System | 12 amp regulated |
| Fuel Gauge | No |
| Governor | Mechanical |
| Choke | Separate Choke |
| Air Filter | Dual element |
| Oil Filter | Yes |
| Fuel Delivery | Carburetor |
| Battery | 210 CCA |
| Battery Type | AGM (Absorbent Glass Mat) |
| Battery Voltage | 12V |
| Transmission | Hydro-Gear ZT 3100 |
| Drive System | Hydrostatic |
| Serviceable Transmission | Yes (Serviceable) |
| Deck Wash | No |
| Deck Material | 10-gauge steel with 2-gauge reinforcement |
| Deck Engagement (PTO) | Electric |
| Deck Lift | Foot pedal with Dial Adjust |
| Blade(s) | Three |
| Anti-Scalping | Three gauge wheels |
| Turning Radius | 0° |
| ROPS | Yes |
| Rear Tow Hitch | Yes |
| Corrosion Protection | Yes |
| Front Caster Yokes | 5/16" Steel |
| Cruise Control | No |
| Brakes | Disc |
| Steering Control | Lap Bars |
| Seat Type | 20" high back |
| Armrests | Yes |
| Seat Adjustment | Lever |
| Front Caster Suspension | No |
| Hour Meter | Yes |
| Mulch Kit | Available separately |
| Cup Holder | Yes |
| Operator Presence System | Yes |
| Parking Brake | Lap Bar Integrated |
| Model Number | 47TSAAA7A10 |
| Commercial Warranty | 4-year 800 hours |
Cub Cadet designs zero-turn mowers with durable construction, operator-focused features, and structured warranty coverage to support consistent performance on residential properties.
